| 最大作業圧力: | 7bar | 最大流量: | 36lpm |
|---|---|---|---|
| 最大回転速度: | 400cpm | 最大吸着高さ: | 3.5m |
| 最大 許容 さ れ た 穀物: | 2.5mm | 最高の空気消費: | 8.510L/s |
| エアインレットサイズ: | 1/4 イン | 空気出口 サイズ: | 3/8インチ |
| 流体の入口サイズ: | 1/2 3/4 in | 流体アウトレットサイズ: | 1/2 3/4 in |
| 重さ: | 16のKG | 横隔膜材料: | PTFE |
| ポンプの体材: | アルミニウム | アウトレットサイズ: | 1/2 |
| 電源: | 空気圧 | ||
| ハイライト: | RV PTFE diaphragm pump 36lpm,pneumatic diaphragm pump 100psi,PTFE diaphragm pump high flow |
||
| Attribute | Value |
|---|---|
| Warranty | 1 year |
| Customized Support | OEM, ODM |
| Power Source | Pneumatic |
| Structure | Diaphragm Pump |
| Outlet Size | 1/2 |
| Material | PTFE |
| Color | Black |
| Weight | 16kgs |
| Diaphragm | PTFE |
| Brand | RV |
| Packing | Carton |
| Max Pressure | 100psi (0.7Mpa, 7bar) |
| Pump Body | Aluminum |
| Max Flow | 36lpm |
| Max Working Pressure | 7bar |
| Max Flow Rate | 36lpm |
| Max Reciprocating Speed | 400cpm |
| Max Suction Height (Dry Sucking) | 3.5m |
| Max Permitted Grain | 2.5mm |
| Max Air Consumption | 8.510L/S |
| Air Inlet Size | 1/4 in |
| Air Outlet Size | 3/8 in |
| Fluid Inlet Size | 1/2 3/4 in |
| Fluid Outlet Size | 1/2 3/4 in |
| Weight | PTFE pump 16 kg |
Jiangliang Technology Co., Ltd is headquartered in Shanyang Town, Jinshan District of Shanghai, with 2 production bases and 3 branches in the mainland of China.
Shanghai Jianglang has been awarded as High-Tech Enterprise and Credit Company title in consecutive years. We have strong capability of design, innovation, precision production and tight cooperation with Shanghai universities.
Our main products are diaphragm pumps and control valves, including: Pneumatic Diaphragm Pump, Electric Diaphragm Pump, Piston Pump, Powder Pump, Sanitary Pump, Diaphragm Pump with Leakage Detector Controller, Pneumatic Diaphragm Regulating Valve, Control Valve, Sequencing Valve and related products.
The pumps and valves have been granted more than 40 patents, including 10 invention patents. Jianglang participated in setting norms and standards for technical specification for pneumatic diaphragm pumps in petrochemical industry.
